Capability
CNC Milling Services in Fruitport, Michigan
We offer versatile CNC milling for precision components and complex geometries, on 14 CNC mills programmed in Mastercam, for manufacturers in Fruitport and across West Michigan.
The mills
14 CNC millsOur mills are Doosan, Haas and Fanuc, with 4th axis rotary capability.
- Doosan VC3600 Swing Tables
- Haas VF2, VF4, VF3TT & VF1
- Doosan DNM 5700 Vertical machining center
- Fanuc Robo Drill
- 4th Axis Rotary Capability
Doosan DNM 5700
Our Doosan DNM 5700 carries a 51.2" x 22.4" table capable of handling up to 2,205 lbs, with travels of 41.3" in X, 22.4" in Y and 20" in Z. Spindle speed, torque and tooling are listed with the full equipment list.
Tolerance
Standard tolerance
+/- .001
We will hold up to +/- .0005, though a tolerance that tight typically requires additional outside services, such as grinding.
Programming
We use MasterCam CAD/CAM software for our CNC mills and lathes, primarily on Fanuc controls with G+M coding. We check milled parts on our inspection equipment before they ship.
Request a Quote
Have a milled part to quote?
Send part drawings by email to office@leemfg.net, with your company name and part number.
